Machine Specifications
| Specification | Bed Length – 850U mm | Bed Length – 1300U mm | |
|---|---|---|---|
| Capacity | Maximum Swing | 370 mm / 14.60 in | 370 mm / 14.60 in |
| Maximum Machining Diameter | 344 mm / 13.500 in | 344 mm / 13.500 in | |
| Maximum Machining Length | 860 mm / 33.900 in | 1325 mm / 52.200 in | |
| Main Spindle | Maximum Speed | 5000 rpm | 5000 rpm |
| Second Spindle | Maximum Speed | 5000 rpm | 5000 rpm |
| Turret (Upper) | Number of Tools | 12 | 12 |
| Maximum Speed | 6000 rpm | 6000 rpm | |
| Feed Axes | Travel (X-Axis) | 207 mm / 8.20 in | 207 mm / 8.20 in |
| Travel (Y-Axis) | 100 mm / 4.00 in | 100 mm / 4.00 in | |
| Travel (Z-Axis) | 760 mm / 29.87 in | 1225 mm / 48.25 in | |
